PRODUCT OVERVIEW

Stunning Ultra-HD Visuals

All three models feature a massive 4K UHD (3840×2160) display with Direct-lit LED backlighting and a wide 16:9 format. Available in 65″ (C6530), 75″ (C7530), and 86″ (C8630), they offer high brightness (~350 cd/m²), wide viewing angles (178°/178°), and vibrant color performance (90% NTSC, ΔE ≤ 2). Zero-parallax optical bonding delivers crisp and accurate visuals, ideal for presentations, video playback, and detailed collaboration.

Responsive Multitouch Experience

Each panel uses IR touch technology supporting up to 20 simultaneous touch points, with a minimum object detection around 2 mm and ±1 mm accuracy. Response times range from 8 to 8.5 ms, providing real-time annotation and seamless interaction during meetings or teaching sessions.

Professional-Grade Conferencing

Equipped with a built-in 48 MP camera featuring full WDR and auto-framing, as well as an 8-element beamforming microphone array with up to 8 m pickup range, these panels ensure clear video and audio for hybrid meetings. Whether hosting a small team or a full room, voice tracking and AI-enhanced audio clarity keep communication sharp and focused.

Immersive Audio Output

A powerful 2.1-channel sound system—combining two 10 W satellites with a 20 W subwoofer—delivers deep, full-range audio suitable for conference calls, multimedia playback, and instructional environments. Integrated echo cancellation and AI noise suppression enhance sound quality and professionalism.

Flexible Operating System & Connectivity

Running MAXHUB OS 6 on Android, these panels support wireless screen sharing (MAXHUB Share, Miracast, AirPlay, Chromecast) and advanced whiteboarding with OCR and templates. They include a full connectivity suite: HDMI in/out, USB (2.0/3.0), USB-C, touch, RS-232, audio out, and an OPS slot for optional Intel PC modules (10th Gen i5/i7).

Features

• Sizes: 65″ / 75″ / 86″ all in 4K UHD
• Display: Direct-lit LED, 90% NTSC, ΔE≤2, 8 ms response
• Touch: 20-point IR, ±1 mm accuracy, min object ≥2 mm
• Camera: 48 MP with WDR & auto-framing
• Mic: 8-element beamforming array, 8 m range
• Audio: 2.1 Seam speakers (2×10 W + 20 W sub)
• OS & Sharing: Android OS, wireless screen sharing, smart whiteboard
• Connectivity: HDMI in/out, USB 2.0/3.0, USB‑C, touch, RS‑232, audio out, OPS slot
• Power: AC 100–240 V, max 350–400 W, standby ≤0.5 W
• Installation: VESA mounting, includes stylus, cables & mount kit
